Sun-blind ultraviolet image intensifier

The ultraviolet light in the 200~280nm band is also called Sun-blind ultraviolet. The Sun-blind ultraviolet image intensifier is a double close-attachment focusing image intensifier with ultraviolet transparent quartz glass as the input window, and the output window can be a fiber optic invertor or a fiber optic panel. We have successfully developed an antimony cesium photocathode UV image intensifier using the existing image intensifier technology.
More Details

The product adopts advanced technology, is not interfered by the visible spectrum, and can convert the weak, non-harmful ultraviolet radiation image into a visually visible image.

The main components of the Sun-blindUV image intensifier include antimony cesium photocathode, dual MCP, aluminum-plated phosphor screen, and a built-in integral power supply consisting of an oscillator and a voltage doubler.

Product features: not interfered by the visible spectrum; dual MCP; external CCD output electrical signal, digital recording and processing; close focus, low distortion; adjustable gain and output brightness.

Product application: ultraviolet alarm, ultraviolet communication; ultraviolet fingerprint recognition; ultraviolet corona meter; medical, industrial, scientific research; fluorescence analysis, particle detection, etc.
